的用途与百度百科/Brief Introduction：

变频化轴向柱塞泵泵式膏体酱装灌机是你工厂满足贸易需求量开发技术的新车辆。这个机器使用SUS304304不锈钢轴向柱塞泵泵式计量校准泵施行装灌，且集系统重新化上盖、系统重新化旋盖、汽车电器电力电气为一体化，资金入门，占屋面空间小，广泛性操作于医药集团、美食、药剂、纸业、彩妆品等市场的夜体进行包装，合乎GMP标准耍求。Automatic plunger paste paste filling machine is my company to meet the market demand, introduction of foreign advanced technology to develop new products. This machine adopts SUS304 stainless steel plunger metering pump filling, cover and set for automatic, automatic screw cap, integration of the mechanical and electrical, economical and practical, cover an area of an area small, widely used in pharmaceutical, food, pesticides, chemical industry, cosmetics and other industries of liquid packaging, full compliance with GMP requirements.

特征 /characteristic：

◆使用柱塞泵式计量校准泵强制执行包装，实用种种胶状度液态，控制精度更高；泵的空间结构使用快接式拆除医院，尽可能使擦拭、消毒杀菌。Adopt plunger type metering pump filling, used various viscosity liquid, high precision; The structure of pump adopts fast disassembly institutions, easy cleaning and disinfection◆注塞泵式的计量泵活塞式环质地依据制造业及药液物质的有所不同适用硅聚氨酯，四氟氯乙烯或各种质地，专项 商务活动适用陶瓷制品质地。Plunger metering pump piston ring material according to the industry and different adopt silicon rubber, liquid ingredients tetrafluoroethylene or other material, special occasions with ceramic material◆PLC保持体系，变频式变速，定时化程度较高。PLC control system, frequency control of motor speed, a high degree of automation◆缺瓶不罐装，系统自动计数器作用。Lack of bottle filling, automatic counting function◆装量整改有利，可是一次整改任何计算校准泵的充填量，也可争对不同的计算校准泵采取微幅整改；作业用简，整改快捷。The load adjustment is convenient, can be a filling quantity of all pumps also can be slightly adjusted according to various metering pump; Simple operation, rapid adjustment◆装灌针头要设防漏滴控制系统，充填时溜进瓶底装灌，迟缓回落，避免 气泡图片。Filling needles a drip-proof device, filling into the bottom of the bottle filling, slowly rising and prevent bubbles.◆组装机可实用不同于品种的塑料瓶子，調整简单，可在多日间内达到。The machine is suitable for various specifications of bottles, easy adjustment, it can be finished in a short period of time◆整体按GMP符合要求设计方案。The machine designed according to the requirements of GMP

枝术性能/technic parameter：

不适用塑料瓶子的规格Size of bottles	20-1000ml（按照追求生产厂家）20-1000 - ml (according to your need）
用于可乐瓶厚度Apply the bottle diameter	¢20-¢150mm
可用于盖子标准Apply the lid specifications	¢20-¢70mm
产生实力 production capacity	四头包装：1000-2500瓶/H Four filling head: 1000-2500 bottles per hour 八头灌装设备：2500-4000瓶/小时英文 Eight head filling: 2500-4000 bottles per hour 12头灌装线：4000-6000瓶/一小时 12 head filling: 4000-6000 bottles per hour
装量误差率The load error	±1%
旋盖达标率率Screw cover percent of pass	≥99%
电power supply	380V，50HZ
耗油率power	3.0KW
气动阀门gas sources	0.4-0.75MPA
快速掌控speed control	交流变频调速器variable speed
