用处与详细资料/Brief Introduction：

终端服务器用到专项 三通管分装阀，适宜于水剂和膏霜产品的的分装，很大对高粘合度物品（如浓酱、青椒酱、番茄酱、种衣剂、微乳剂、自主化隐藏剂等）的视觉效果是比较强烈，且精确高。终端服务器用到PLC可c语言编程把控，和6厘米接触屏人机对战软件界面系统的，全面推行自主化进瓶，自主化分装，自主化出瓶，电器电线电缆，气动弹簧元部分均用到國際的品牌，保障了不错的耐磨性和耐用保持稳定的耐磨性。本的设施构造十分简单，作业方便快捷，是中国梦想的专门针对高粘合度物品的分装的设施。终端服务器配齐了必免漏滴与磨砂机的分装闷头，保障分装成功后无漏滴，无磨砂机。Filling valve, the machine USES special tee is suitable for the filling agent and cream products, especially for high viscosity material (such as thick sauce, chili sauce, tomato sauce, indicated, micro emulsion, suspending agent, etc.) of the effect is obvious, and high precision. The machine USES PLC programmable control, with 6 inch touch screen man-machine interface system, implements the automatic into the bottle, automatic filling, automatic bottle, electric, pneumatic components adopt international brand, to ensure that the performance of the outstanding quality and lasting stability. This equipment has simple structure, convenient operation, is the ideal filling equipment for high viscosity material. The machine is equipped with prevent drip with wire filling cocks, ensure filling after the completion of a drip-tight, no drawing.

结构特征/Characteristic：

◆操控机设备——用到西门子PLC操控机设备，罐装用量随时细调。Control system adopt mitsubishi PLC control system, filling dose random tweaks◆工作的用户介面——64英寸彩屏手触式工作的用户介面，最直观简易、安全安全Interface - 6 inches color hand touch interface operation, intuitive and simple, safe and reliable◆职能改造——上下料有防滴漏问题平衡装置，可跟据介质属性符合下潜罐装职能。（此职能能够用）Improvements - blanking drip tight device, according to the material properties have diving filling function. (this function can be chosen)◆电器产品元器件封装——均选取国际性顶级企业，加强组织领导产品的应急牢靠、准确的高；Electrical components adopt international famous brand, to ensure the equipment safe and reliable, high accuracy;◆机械制造构件——电脑构件均进行优良304不锈钢板质作,烦请需求接触的面积货位还可以进行316L另结算用。Mechanical parts, machine parts are made of high quality 304 stainless steel material can be used if necessary contact 316 l in extra costs.◆运算法监测——实时视频运算法，对业务总产量客观事物表现形式。Counting test, real-time, intuitive reflect the yield of work.◆装灌检验——无瓶不灌、瓶数不能不灌Bottle filling test - no bottle no filling, not enough◆系统维持情况报告——该机按照GMP标准要求，可高效替换、洗掉系统维持。Maintenance - the machine is in line with the GMP requirements, easy disassembly, cleaning maintenance.◆置换样式——改换灌装设备样式时，只需要快速修正，快速就搞定。Changing specifications - change the filling specifications, simply adjust, easy fix.◆环镜手机分配——手机分配了环镜框架图，使系统的进行操作环镜十分清理卫生学。（此环镜手机分配能够 加配）Environmental protection configuration, configuration framework of environmental protection, make the operation of the machine environment more clean sanitation. (the environmental protection configuration can be selected)

技术水平基本参数/technical parameters：

灌装设备头数The number of filling head	8🥂头（可以选择4、6、8、10、12罐装头）8 head (optional 4, 6, 8, 10, 12 filling head)
适合瓶径 Applicable bottles Drive	Ф33-Ф100 mm
压力容器检验gps精度measure precision	±1%
罐装发热量Canned capacity	150-1000ml
的生产能利用率力Production Capacity	2400-4000瓶/每小时2400-4000   bottles per hour
气源压力bleed pressure	0.7-0.9mpa
电    源Power Supply	380 伏/50 HZ
总 功 率The total power	0.5 kw
外形尺寸 boundary dimension	6000×850×1800 mm
重    量Weight	500kg
