贷款用途与简单介绍：/Purpose and introduction

服食液洗烘灌轧联合线由落地式彩超波洗瓶机、隧道口式暧风 反复过滤除菌烘烤箱、服食液装灌轧盖机等组建，非常适合于 5-30ml 等不同的规 格服食液瓶的产生。可达到对医疗耗材产生中安瓿瓶淋水、彩超波擦拭、冲水、充 气、干燥过滤除菌、冷却后、装灌、轧盖等工序步聚的联合程序运行。Oral liquid washing drying filling and rolling line by the vertical ultrasonic bottle-washing machine, tunnel sterilization oven hot wind cycle, oral liquid filling and other components of the rolling machine, suitable for 5-30 ml different gauge, etc Oral liquid bottle production. Can be done for ampoule bottle pour water in drug production, ultrasonic cleaning, flushing, filling gas, drying sterilization, cooling, filling and rolling cover joint operation of the process steps.

优点和缺点:/characteristic

◆洗瓶机分为机械制造手夹瓶，用于三种的规格的小瓶；Bottle washer adopts manipulator clamp bottle, is suitable for a variety of specifications of the bottle;◆洗瓶采取热气喷针反复追综加入措施，清理的好用，浪费能源技术。并存在针架防颤抖装制，提高了喷针加入矿泉水瓶的合理度，减小断针状况發生；Reciprocating mixer washing bottle with water spray needle track insert way, cleaning effect is good, save energy. And is equipped with needle shake device, improve the accuracy of injection needle inserted into the bottle, reduce breakage phenomenon;◆洗瓶全部水雾滤油器、喷针可以自己错开，减少了穿插感染，适用GMP规范化标准要求；Mixer washing bottle the water pipe, injection needles completely separate, to avoid the cross contamination, in line with the GMP requirements;◆洗瓶机进瓶挤出机螺杆式前装个抗震块，有呵护挤出机螺杆式，极大减少碎瓶角色Pieces into the bottle inside the screw before adding buffer block, protect the screw, reduce broken bottles◆洗瓶机出瓶采取产品原装进口一起带，连结拨块传送服食液，程序运行不稳稳定可靠In pieces out of the bottle inside the whole import synchronous belt, the connection piece of conveying liquid, stable and reliable running◆干燥箱用到红外线升温管，不绣钢升温管双层线路升温体温均匀分布性好；Oven using infrared heating tube, stainless steel heating tube double heating temperature uniformity is good;◆灌装生产线轧盖机可供选择配卫浴陶瓷泵、不锈钢板泵；In pieces filling rolling machine optional ceramic pump, stainless steel pump;◆装灌无瓶止灌，无瓶不轧盖作用。Pieces filling without bottle filling, no bottle no rolling function.◆整线利用PLC总把控好、直流变频空调器、触感屏把控好技艺，程序正常运作安稳可信度。触感屏可表明各单机联机的程序正常运作形态下，各把控好点的通水压力、汽压、压力、温度因素等表明，各启闭形态下和出现错误表明，出现错误自我表现判断和出现错误阐述及排除故障手段。使全部整个制造销售历程达到自功化把控好，联线拥有三机自我控制动态平衡设备，做到制造销售动态平衡可信度。The whole line adopts PLC control, inverter, touch screen control technology, stable and reliable running. Touch screen can display the running state of each units, each control point of the water pressure, air pressure, air pressure, temperature, etc, according to the switch state and fault display, fault self-diagnosis and fault analysis and elimination method. The whole production process to achieve automatic control, on-line has the compressors control balancing device, ensure production is balanced.结合企业客户的须要，还可供配搭：According to the needs of customers, but also available for selection:◆欧姆龙、德力西、三菱数控操作系统、台达等厂家掌控操作系统；Pieces of Siemens, schneider, mitsubishi, Taiwan brands such as control system;◆水、气气压、水温表及彩超波抗拉强度、尘埃什么意思a粒子、风力在线上检查、报案、记下、打印机软件。Pieces of water, gas pressure, water temperature and the intensity of ultrasonic, dust particles, wind speed on-line detection, alarm, record and print system.◆ORABS、CRABS、无菌室防晒隔离霜器整体。Mixer ORABS, CRABS, aseptic isolator system.

水平因素：technical parameters

适用于品种Cutting   dimension(ml)	5-25
生产能力production capacity(pcs/min)	350
分装定位精度Filling accuracy(%)	≤ ± 2.5
分装头数Fillingheads	16
轧盖头数Number of rolling   curtain	单刀20头
轧盖不成品率Rolling cover   percent of pass(%)	≥ 99
总重量total weight(kg)	7500
外形尺寸boundary dimension(mm)	9920 × 2003 × 2150
