的主要用途与详细资料/Brief Introduction：

该线由水平线式挤出机螺杆洗瓶风干成触控一体机、服食液罐装轧盖机二台单人包含，包含擦拭、非常干燥灭菌方法处理和罐装密封几个工作的区，全程可联合生产加工，也可单人食用。可提交淋水、超声心动图波擦拭、冲水、冲气、风干灭菌方法处理、降温、罐装、理盖、戴盖、轧盖等程序。The line is made up of two single machine, one straight-line screw bottle washing and drying machine and one oral liquid filling and capping machine. The line is divided into cleaning, drying, sterilization and filling sealing three workspace, all can joint production, also can use single. It can complete water spray, ultrasonic cleaning, water flushing, air flushing, drying sterilization, cooling, filling, cap arranging, capping, sealing, etc.

优缺点/Characteristic：

选用超声洁净波洁净及水蒸气跳变情况呢、远红外高温高压灭菌方法、多头多碇灌装设备与塑封等科技。整线协同自功抑制。进行单纯利于，保证 了机械分立式化。Using ultrasonic cleaning and water washing alternately, far-infrared high-temperature sterilization, such as long filling and sealing technology. The automatic control of the whole line linkage. Simple and convenient operation, electromechanical integration is realized.

技术设备叁数/ Technical Parameters：

生产能力technical parameters	80-150瓶/分80-150 bottles/min
符合年纪 Cutting dimension	5-20ml
电  容  量Amount of electric capacity	65Kw(中间普通 运作36Kw)(including normal working 36 kw)
工具净重量machine net weight	6800Kg
外形尺寸boundary dimension	9650×2360×1900mm（长×宽×高）(length x width x height)
